Geekworm Raspberry Pi 3 B+/3B SATA HDD/SSD Storage Expansion Board, X820 V3.0 USB 3.0 Mobi

Product Description

Notice:
The Raspberry Pi 3 Board & 2.5inch SATA interface HDD/SDD is not included.

[Overview]
- This X820 expansion board provides a complete storage solution for raspberry pi, only 2.5 inch SATA interface HDD/SDD hard disk is suitable for X820 Board;
- For Use With: Raspberry Pi 3 Model B/ 2B / B+
- Upgraded to USB3.1 Gen1 port; (SupportS USB 3.0) w/ high quality USB 3.0 Cable ( Lenght- 80cm/2.62inch; Diameter- 5.96mm/0.19inch)
- Operating System: All Raspberry Pi operating systems

[Features]
- Supports upto 4TB 2.5-inch SATA hard disk drives (HDD) / solid-state drive (SSD)
- Ideal storage solution for Raspberry Pi
- USB 3.1 Gen1 to SATA 6Gb/s Bridge Controller
- USB 2.0 connectivity offers plug-and-play functionality on your Raspberry Pi
- Quick file transfer with high-speed USB 3.0 connectivity from a PC or a Mac
- External Self Powered - Do not require power from Raspberry Pi USB port
- Powers the Raspberry Pi - no additional power supply for RPi
- Duplicated Raspberry Pi HDMI port

[Specification]
- Power supply: AC 100 - 240V input 50 / 60Hz, 5V DC 4A output
- DC Power Plug Size : 5.5*2.5mm
- Output Ports: 1 x HDMI, 1 x USB , 1 x DC jack
Notice:
1/ DO NOT APPLY POWER TO YOUR RASPBERRY PI VIA THE PI's MICRO USB SOCKET!
2/ The Max. voltage is 5V, if over 5V, the X820 board may be damaged.
3/ Please use X820 board with a good quality power supply(for X820 with Power Kit, search with ASIN: B073QLHLMT). The power adapter powers not only the Raspberry Pi , but also the SSD/HDD. If the power is low, the SSD/HDD may not be identified.

[Packing List]
1 x X820 Expansion Board
1 x USB 3.0 cable (Length: 80cm/ 2.62 inch)
1 x USB connector
1 x 2 Pin Power Connection Wire(Cable: 10cm)
1 x HDMI Adapter
1 x Install Screws pack
[Installation Guide & more details]
Please refer to the WIKI: http://www.raspberrypiwiki.com/index.php/X820

Features

• ? Please use this high quality certified DC 5V 4A power supply(ASIN :B07413Q5Y4).Power supply request: 5Vdc +/-5% , 4A; The power adapter not only powers Raspberry Pi board but also powers your SSD or HDD. If the power is low, the SSD/HDD may not be identified or damage your RPi or X820 board. [Do Not Use ASIN:B01K0608A0!!!]
• ? Raspberry Pi SATA X820 V3.0 HDD/SSD USB3.0 shield expansion board provides an complete storage solution for Raspberry Pi 3B+/3B motherboard, Support up to 4TB 2.5 inch SATA interface hard disk drives (HDD) / solid-state drive (SSD). A good raspberry pi sata adapter for Raspberry Pi 3B+, 3B, 2B, B+. Note: For Raspberry Pi 4 Model B 2.5 inch SATA HDD/SSD storage board, please refer to ASIN:B07VXF2HJG; For Raspberry Pi 4 Model B mSATA SSD storage board, please refer to ASIN: B07VXFGFLX
• ? X820 V3.0 supports USB booting from your HDD/SSD('reboot' command is supported), a useful and reliable function to every raspberry pi users or fans. Suggest to use with geekworm x820 metal case(ASIN :B07GRZRW7J); User manual, pls refer to Geekworm WiKi search(X820).
• ? Powers the Raspberry Pi via Pi's 40-pin header or Micro USB socket; Furthermore, On-board XH2.54 connector and USB power socket (5V 2A output) to power other devices, such as smartphone, tablet... WARNING:Do not power your Raspberry Pi via the Pi's 40-pin header and micro-USB socket at the same time.
• ? X820 can be used as a USB3.0 Mobile Hard Disk when connecting a 2.5 inch SATA interface HDD/SSD do not need extra power and free driver installation. Quick file transfer with high-speed USB 3.0 connectivity from a PC or a Mac.
